DescriptionSpecification
OC-3 MM: 2 km (1.2 miles)OC-3 SR: 2 km (1.2 miles)OC-3 IR-1: 15 km
(9.3 miles)OC-3 LR-1: 40 km (24.8 miles)OC-3 LR-2: 80 km (49.7 miles)
Cabling distance (maximum)
OC-3 MM: 23 to 185 degrees F (–5 to 85 degrees C)OC-3 SR: 23 to 185
degrees F (–5 to 85 degrees C)OC-3 IR-1: 23 to 185 degrees F (–5 to 85
degrees C)OC-3 LR-1: 23 to 185 degrees F (–5 to 85 degrees C)OC-3 LR-2:
23 to 185 degrees F (–5 to 85 degrees C)
Operating case temperature
range
OC-3 MM: –19 to –14 dBmOC-3 SR: –15 to –8 dBmOC-3 IR-1: –15 to
–8 dBmOC-3 LR-1: –5 to 0 dBmOC-3 LR-2: –5 to 0 dBm
TX power
OC-3 MM: –30 dBmOC-3 SR: –23 dBmOC-3 IR-1: –28 dBmOC-3 LR-1:
–34 dBmOC-3 LR-2: –34 dBm
Receiver sensitivity (maximum)
OC-3 MM: –5 dBmOC-3 SR: –8 dBmOC-3 IR-1: –8 dBmOC-3 LR-1: –10
dBmOC-3 LR-2: –10 dBm
RX overload
OC-3 MM: +5 dBmOC-3 SR: +5 dBmOC-3 IR-1: +5 dBmOC-3 LR-1: +5
dBmOC-3 LR-2: +5 dBm
Maximum receiver power
damage
8-Port OC-3/STM-1 POS SPA Overview
The 8-Port OC-3/STM-1 POS SPA is a single-height SPA that installs into one SIP subslot. The SPA with
small form-factor pluggable (SFP) optical transceiver modules provides Optical Carrier Level (OC-n ) for
SONET and Synchronous Transport Module (STM-n ) for SDH network connectivity. On this SPA, any given
port can use an OC-3 SFP module, so the per-port bandwidth can be 155.52 Mbps.
When SFP modules are replaced, the SPA interface retains any previously defined configurations. These
configurations include settings for IP address, clock source, loopback, CRC, and POS flags.
Note
For more information about SPA bandwidth, see the “Bandwidth Oversubscription” topic in this chapter.
For more information about SPAs and their compatibility with SIPs and modular optics, see the “SIP and
SPA Product Overview” chapter in this guide.
The following sections describe the 8-Port OC-3/STM-1 POS SPA:
8-Port OC-3/STM-1 POS SPA LEDs
The 8-Port OC-3/STM-1 POS SPA has three types of LEDs: two LEDs for each port on the SPA and one
STATUS LED. The following figure shows the 8-Port OC-3/STM-1 POS SPA faceplate.
Cisco ASR 9000 Series Aggregation Services Router SIP and SPA Hardware Installation Guide
41
Overview: Cisco ASR 9000 Series Router Shared Port Adapters
8-Port OC-3/STM-1 POS SPA Overview
