Cisco ASR 1001-X Router Hardware Installation Guide
OL-32376-02
Chapter 3 Preparing Your Site for Installation
Site Planning
Physical Characteristics
Be familiar with the physical characteristics of the Cisco ASR 1001-X Router to assist you in placing
the system at a proper location.
Note For information regarding rack widths supported for the Cisco ASR 1001-X Router, see the following
sections:
• 19 in.—“General Rack-Selection Guidelines” section on page 3-15
• 23 in.—“Guidelines for 23-in. (Telco) Racks” section on page 3-16
Table 3-3 shows the weight and dimensions of the Cisco ASR 1001-X Routers.
The following list describes additional Cisco ASR 1001-X Router characteristics:
• Chassis height meets EIA-310 rack spacing 1RU (1.71 in. or 43.43 mm), universal rack mount
• Chassis width meets EIA-310 19 in. (17.3 in. or 439.42 mm) wide with rack brackets
• Cable-management brackets allow a bend radius of 1.5 in. (38.1 mm) for cables
• Ships with forward rack-mount brackets installed and an extra set included in the accessory kit
Thermal shock nonoperating with change over time
of 3 minutes
–25° C +70° C
Thermal Shock - Operating at 2.5 degree C per
minute
0° C +50° C
Table 3-2 Cisco ASR 1001-X Router Environmental Tolerance (continued)
Environmental Characteristic Minimum Maximum
Table 3-3 Physical Characteristics of Cisco ASR 1001-X Router
Characteristic Cisco ASR 1001-X
Height 1.71 in. (43.43 mm) —1RU; rack-mount per
EIA RS-310
Width 17.3 in. (439.42 mm)
Depth 22.50 in. (571.5 mm) Depth includes
cable-management brackets; card and
power-supply handles for mounting in a 600
mm enclosed cabinet.
Weight 25 lb (11.35 kg) fully loaded

Cisco ASR 1001-X Specifications

General

Product color	Gray
Rack capacity	1U
Rack mounting	Yes
Networking standards	-
Ethernet LAN (RJ-45) ports	6
Installed SFP modules quantity	2
Flash memory	1024 MB
Internal memory	8192 MB
Processor cores	4
AC input voltage	85 - 264 V
Power source type	AC
Power consumption (typical)	250 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Security algorithms	AES

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	10590 g
