Cisco ASR 9001 Hardware Installation Guide

• Auxiliary port—RJ-45 interface for connecting a modem.
The console and auxiliary ports are asynchronous serial ports. Ensure that devices connected to these ports
are capable of asynchronous transmission.
Note
Console Port Signals
The RP console port is an RJ-45 interface for connecting a terminal to the router. The console port does not
support modem control or hardware flow control and requires a straight-through RJ-45 cable.
Before connecting a terminal to the console port, check the terminal setting for the data transmission rate, in
bits per second (bps). The terminal transmission rate setting must match the default rate of the RP console
port, which is 115200 bps. Set the terminal to these operational values: 115200 bps, 8 data bits, no parity, 1
stop bits (115200 8N1).
The following table lists the signals used on the RP console port.
Table 4: RP Console Port Signals
DescriptionInput/OutputSignalConsole Port Pin
Request to SendOutputRTS1
(Not connected)
——
2
Transmit dataOutputTxD3
Signal ground
—
GND4
Signal ground
—
GND5
Receive dataInputRxD6
(Not connected)
——
7
Clear to SendInputCTS8
Auxiliary Port Signals
The RP Auxiliary (AUX) port is a RJ-45 interface for connecting a modem or other data communication
equipment (DCE) device (such as another router) to the RP. The AUX port supports hardware flow control
and modem control.
The following table lists the signals used on the Auxiliary port.
Cisco ASR 9001 and Cisco ASR 9001-S Routers Hardware Installation Guide
26
Preparing for Installation
Console Port and Auxiliary Port Connection Guidelines
