Cisco ASR 9001 Hardware Installation Guide

MeaningStateColorLED Label
Port is enabled and the
link is down.
OnAmber
Modular port adapter
power is off.
OffOffSTATUS
Modular port adapter is
ready and operational.
OnGreen
Modular port adapter
power is on and good, and
the modular port adapter
is being configured.
OnAmber
Installing and Removing Modular Port Adapters
These sections describe how to install or remove modular port adapters (MPAs) on the Cisco ASR 9001
Router.
Handling Modular Port Adapters (MPAs)
Each modular port adapter (MPA) circuit board is mounted on a metal carrier, and is sensitive to electrostatic
discharge (ESD) damage. Before you begin installation, refer to the Cisco ASR 9000 Series Aggregation
Services Router Ethernet Line Card Installation Guide for a list of parts and tools required for installation.
Always handle the modular port adapter (MPA) by the carrier edges and handle; never touch the modular
port adapter (MPA) components or connector pins. (see the following figure.)
Caution
When a bay is not in use, a blank ASR 9000 MPA Slot Filler (A9K-MPA-FILR) must fill the empty bay to
allow the router to conform to electromagnetic interference (EMI) emissions requirements and to allow proper
Cisco ASR 9001 and Cisco ASR 9001-S Routers Hardware Installation Guide
67
Installing Modules and Cables in the Chassis
Installing and Removing Modular Port Adapters
