Cisco ASR 903 Hardware Installation Guide

1PPS (input and output)10 Mhz (input and output)
Input— > 2.4 volts TTL
compatible
Output— > 2.4 volts TTL
compatible
Input— > 1.7 volt p-p(+8 to +10
dBm)
Output— > 2.4 volts TTL
compatible
Amplitude
50 ohms50 ohmsImpedance
26 microseconds50% duty cyclePulse Width
40 nanoseconds
Input—AC coupled
Output—5 nanoseconds
Rise Time
Time of Day Port Pinout
The table below summarizes the ToD port pinout for ASR900-RSP1-55.
Table 20: RJ45 ToD Port Pinout
DescriptionDirectionSignal NamePin
1PPS RS422 signalOutput or Input1PPS_P1
1PPS RS422 signalOutput or Input1PPS_N2
Do NOT connectOutputRESERVED3
GND4
Time of Day characterGND5
Do NOT connectInputRESERVED6
Time of Day characterOutput or InputTOD_P7
Time of Day characterOutput or InputTOD_N8
The table below summarizes the TOD pinout for A900-RSP2A and A900-RSP3-3C-400 modules.
This port requires the use of SHIELDED cable for GR-1089-core “Intra-Bldg lightning surge” protection.
RS422 interface is per industry standard EIA-422 /RS422 specification.
Note
Cisco ASR 903 Aggregation Services Router Hardware Installation Guide
147
Troubleshooting
Time of Day Port Pinout
