9-4
Cisco IE 3000 Switch Software Configuration Guide
OL-13018-03
Chapter 9 Configuring PTP
Displaying the PTP Configuration
Displaying the PTP Configuration
To display the PTP configuration, use one or more of these privileged EXEC commands in Table 9-2.
Step 4
ptp {announce {interval value |
timeout value} | delay-req
interval value | enable | sync
{interval value| limit value}}
Specify the settings for the timing messages. These options are only available
when the switch is in boundary mode.
• For announce interval, specify the time for sending announce messages. The
range is 0 to 4 seconds. The default is 1 (2 seconds).
• For timeout value, specify the time for announcing timeout messages. The
range is 2 to 10 seconds. The default is 3 (8 seconds).
• For delay request interval, specify the time recommended to the member
devices to send delay request messages when the port is in the master state. The
range is –1 second to 6 seconds. The default is 5 (32 seconds).
• For sync interval, enter the time for sending synchronization messages. The
range is –1 second to 1 second. The default is 1 second.
• For sync limit, specify the maximum clock offset value before PTP attempts
to resynchronize. The range is 50 to 500000000 nanoseconds. The default
is 50000 nanoseconds.
Note We recommend against setting the sync limit below the default (50000
nanoseconds). Use values below 50000 nanoseconds only in networks
with a high-precision grand master clock.
Step 5
end Return to privileged EXEC mode.
Step 6
show running-config Verify your entries.
Step 7
copy running-config
startup-config
(Optional) Save your entries in the configuration file.
Command Purpose
Ta b l e 9-2 Commands for Displaying the PTP Configuration
Command Purpose
show ptp clock Display the PTP clock properties.
show ptp foreign-master-record Display the PTP foreign-master dataset.
show ptp parent Display the parent and grand-master properties.
show ptp port Display all the PTP port properties.
show ptp FastEthernet interface Display the PTP FastEthernet properties on the specified port.
show ptp GigabitEthernet interface Display the PTP GigabitEthernet properties on the specified port.
show ptp time-property Display the PTP time properties.
