7-9
Cisco IP Communicator Administration Guide for Cisco CallManager
OL-4698-01
Chapter 7 Viewing Operational Information
Viewing Operational Information Remotely from a Web Page
Viewing Operational Information Remotely from a
Web Page
Each Cisco IP Communicator device has a web page from which you can view
operational information. You can use this information to remotely monitor the
device and to assist with troubleshooting.
You can also obtain much of this information directly from the
Cisco IP Communicator interface. For more information, see the “Viewing
Operational Information Locally on the Cisco IP Communicator Interface”
section on page 7-3.
Sender Size Size of voice packets, in milliseconds, in the transmitting voice stream.
Rcvr Packets Number of RTP voice packets received since voice stream was opened.
Note This number is not necessarily identical to the number of RTP voice
packets received since the call began because the call might have
been placed on hold.
Sender Packets Number of RTP voice packets transmitted since voice stream was opened.
Note This number is not necessarily identical to the number of RTP voice
packets transmitted since the call began because the call might have
been placed on hold).
Avg Jitter The estimated average RTP packet jitter (dynamic delay that a packet
encounters when going through the network) observed since the receiving
voice stream was opened.
Max Jitter Maximum jitter observed since the receiving voice stream was opened.
RxDisc Number of RTP packets in the receiving voice stream that have been
discarded (bad packets, too late, and so on).
Note The application will discard payload type 19 comfort noise packets
that are generated by Cisco Gateways, which will increment this
counter.
Recvr Lost Packets Missing RTP packets (lost in transit).
Table 7-4 Call statistics displayed on Cisco IP Communicator (continued)
Item Description
