Cisco RV215W Administration Guide

Administering Your Router
Configuring Simple Network Management (SNMP)
Cisco RV215W Wireless-N VPN Firewall Administration Guide 126
11
To enable SNMP:
STEP 1 Choose Administration > SNMP.
STEP 2 Check Enable to enable SNMP.
STEP 3 Enter this information:
STEP 4 Click Save.
Editing SNMPv3 Users
You can configure SNMPv3 parameters for the two default device user accounts
(Admin and Guest).
To configure SNMPv3 settings:
STEP 1 Choose Administration > SNMP.
STEP 2 Under SNMPv3 User Configuration, configure the following settings:
SysContact Enter the name of the contact person for this
firewall (for example, admin or John Doe.)
SysLocation Enter the physical location of the firewall (for
example, Rack #2, 4th Floor.)
SysName Enter a name for easy identification of the firewall.
UserName Select the account to configure (admin or guest).
Access Privilege Displays the access privileges of the selected user
account.

Cisco RV215W Specifications

General

VPN support	3DES, PPTP, L2TP
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.1Q
VPN tunnels quantity	6
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input current	1.67 A
Supported protocols	PPPoE, PPTP, L2TP, RSTP, NAT, DynDNS, PAT, DMZ
Security algorithms	WEP, WPA, WPA2, WPS
Antennas quantity	2
Certification	FCC Class B, CE, IC, UL, cUL, Wi-Fi, C-Tick
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
