Cisco RV215W Administration Guide

Configuring Networking
Configuring the WAN Settings
Cisco RV215W Wireless-N VPN Firewall Administration Guide 33
6
Global Settings
To install a USB modem:
STEP 1 Connect the USB modem. If the modem is supported, it is automatically detected
and appears on the Mobile Network page.
STEP 2 Select Auto or Manual connection mode. Ethernet Connection Recovery works
only if the Connect Mode is set to Auto.
• To enable your modem to establish a connection automatically, select Auto
mode. If you select Auto, you must also either set a Connect on Demand time
or select Keep Alive. Connect on Demand terminates the Internet connection
after it is inactive for the specified period of time (Max Idle Time).
If your Internet connection is terminated due to inactivity, the modem
automatically establishes a connection when a user attempts to access the
Internet. In the Max Idle Time field, enter the number of minutes of idle time
that can elapse before the Internet connection terminates. Choosing Keep
Alive keeps the connection up at all times.
• To connect or disconnect your modem connection manually, select Manual
mode.
The device displays the current modem connection status that includes initializing,
connecting, disconnecting, or disconnected.
STEP 3 Verify that the Card Status field shows that your mobile card is Connected.
These messages might also appear:
• Please set APN manually (because the device is unable to determine the
access point name)
• Searching for service...
• no SIM card
• SIM locked
• SIM busy
• SIM ready
• pin code needed
• pin code error
• Card is locked

Cisco RV215W Specifications

General

VPN support	3DES, PPTP, L2TP
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.1Q
VPN tunnels quantity	6
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input current	1.67 A
Supported protocols	PPPoE, PPTP, L2TP, RSTP, NAT, DynDNS, PAT, DMZ
Security algorithms	WEP, WPA, WPA2, WPS
Antennas quantity	2
Certification	FCC Class B, CE, IC, UL, cUL, Wi-Fi, C-Tick
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
