Cisco RV215W Administration Guide

Configuring Networking
Configuring the WAN Settings
Cisco RV215W Wireless-N VPN Firewall Administration Guide 32
6
STEP 4 Click Save.
Configuring Optional Settings
To configure optional settings:
STEP 1 In the Optional Settings section, configure the following settings:
STEP 2 Click Save.
Configuring a Mobile Network
Use the Mobile Network page to configure the device to connect to a Mobile
Broadband USB modem that is connected to its USB interface.
To display the Mobile Network window, choose Networking > WAN > Mobile
Network.
Host Name Host name of the device.
Domain Name Domain name for your network.
MTU The maximum transmission unit (MTU) is the size of
the largest packet that can be sent over the
network.
The standard MTU value for Ethernet networks is
usually 1500 bytes. For PPPoE connections, the
value is 1492 bytes.
Unless a change is required by your ISP, we
recommend that you choose Auto. The default
MTU size is 1500 bytes.
If your ISP requires a custom MTU setting, choose
Manual and enter the MTU size.
Size MTU size.

Cisco RV215W Specifications

General

VPN support	3DES, PPTP, L2TP
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.1Q
VPN tunnels quantity	6
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input current	1.67 A
Supported protocols	PPPoE, PPTP, L2TP, RSTP, NAT, DynDNS, PAT, DMZ
Security algorithms	WEP, WPA, WPA2, WPS
Antennas quantity	2
Certification	FCC Class B, CE, IC, UL, cUL, Wi-Fi, C-Tick
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
