Cisco RV215W Administration Guide

Configuring Networking
Configuring IPv6
Cisco RV215W Wireless-N VPN Firewall Administration Guide 64
6
STEP 3 Click Save.
Configuring Advertisement Prefixes
To configure the RADVD available prefixes:
STEP 1 Choose Networking > IPv6 > Advertisement Prefixes.
STEP 2 Click Add Row.
STEP 3 Enter this information:
MTU MTU size (0 or 1280 to 1500). The default is 1500
bytes.
The Maximum Transmit Unit (MTU) is the size of the
largest packet that can be sent over the network.
The MTU is used in RAs to ensure all nodes on the
network use the same MTU value when the LAN
MTU is not well-known.
Router Life Time Router lifetime value or the time in seconds that the
advertisement messages exists on the route. The
default is 3600 seconds.
IPv6 Prefix Type Choose one of the following types:
6to4—Allows IPv6 packets to be transmitted over
an IPv4 network. It is used when an end user wants
to connect to the IPv6 Internet using their existing
IPv4 connection.
Global/Local—A locally unique IPv6 address that
you can use in private IPv6 networks or a globally
unique IPv6 Internet address.

Cisco RV215W Specifications

General

VPN support	3DES, PPTP, L2TP
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.1Q
VPN tunnels quantity	6
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input current	1.67 A
Supported protocols	PPPoE, PPTP, L2TP, RSTP, NAT, DynDNS, PAT, DMZ
Security algorithms	WEP, WPA, WPA2, WPS
Antennas quantity	2
Certification	FCC Class B, CE, IC, UL, cUL, Wi-Fi, C-Tick
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
