Modular RAID (mRAID) riser, can optionally be a
riser that supports either:
• Hardware RAID controller card
• Interposer card for embedded SATA RAID
15Mini-storage module socket. Options:
• SD card module with two SD card slots
• M.2 module with slots for either two SATA
M.2 drives or two NVMe M.2 drives
• Cisco Boot-Optimized M.2 RAID Controller
(module with two slots for SATA M.2 drives,
plus an integrated SATA RAID controller that
can control the two M.2 drives in a RAID 1
array)
6
PCIe cable connectors for front-loading NVMe SSDs
on PCIe riser 2
16Chassis intrusion switch (optional)7
Micro-SD card socket on PCIe riser 117Internal USB 3.0 port on motherboard8
-RTC battery, vertical socket9
Summary of Server Features
The following table lists a summary of server features.
DescriptionFeature
One rack-unit (1RU) chassisChassis
Up to two CPUs from the Intel Xeon Processor Scalable Family.
This includes CPUs from the following series:
• Intel Xeon Silver 4XXX Processors
Central Processor
24 DDR4 DIMM sockets on the motherboard (12 each CPU)Memory
Multi-bit error protection is supportedMulti-bit error protection
BMC, running Cisco Integrated Management Controller (Cisco
IMC) firmware.
Depending on your Cisco IMC settings, Cisco IMC can be
accessed through the 1-Gb dedicated management port, the
1-Gb/10-Gb Ethernet LAN ports, or a Cisco virtual interface card.
Baseboard management
Cisco Application Services Engine Hardware Installation Guide
6
Overview
Summary of Server Features
