IP Configuration: RIPv2
Configuring RIP
405 Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x
17
• Key Chain—If MD5 was selected as the authentication mode, enter the key chain to be
digested. This key chain is created as described in the Key Management section.
• Distribute-list In —Select to configure filtering on RIP incoming routes for the
specified IP address(es) in the Access List Name. If this field is enabled, select the
Access List Name below:
• Access List Name—Select the Access List name (which includes a list of IP addresses))
of RIP incoming routes filtering for a specified IP interface. See Access List Settings
for a description of access lists.
• Distribute-list Out—Select to configure filtering on RIP outgoing routes for the
specified IP address(es) in the Access List Name. If this field is enabled, select the
Access List Name below:
• Access List Name—Select the Access List name (which includes a list of IP addresses))
of RIP outgoing routes filtering for a specified IP interface. See Access List Settingsfor
a description of access lists.
STEP 3 Click Apply. The settings are written to the Running Configuration file.
RIPv2 Statistic
To view the RIP statistical counters for each IP address:
STEP 1 Click IP Configuration > RIPv2 > RIPv2 Statistics.
The following fields are displayed:
• IP Interface—IP interface defined on the Layer 2 interface.
• Bad Packets Received—Specifies the number of bad packets identified by RIP on the
IP interface.
• Bad Routes Received—Specifies the number of bad routes received and identified by
RIP on the IP interface. Bad routes mean that the route parameters are incorrect. For
example, the IP destination is a Broadcast address, or the metric is 0 or greater than 16
• Update Sent—Specifies the number of packets sent by RIP on the IP interface.
STEP 2 To clear all interface counters, click Clear All Interface Counters.
