IP Configuration: SLA
Using SLA
419 Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x
19
• Delay—When the result of an IP SLA operation indicates that the state of the tracking
object should change to X from Y, the tracking object performs the following actions:
- The state of the tracking object is not changed and the tracking object starts the
delay timer for the interval.
- If during the time that the timer is set, the original state (Y) is received again, the
timer is canceled, and the state remains Y.
- If the delay timer is expired, the state of the tracking object is changed to X and the
X state is passed to the associated applications.
Using SLA
ICMP-Echo Operations
IP SLA ICMP-Echo operations can be configured in this page. These operations will be
executed according to the frequency entered.
STEP 1 Click IP Configuration > IPv4 Management and Interfaces > SLA > ICMP-Echo
Operations.
The ICMP-Echo operations are displayed (some fields described in the Add page):
• State—Displays either Pending or Scheduled, as described in the Overview above.
• Return Code—Displays either OK or Error, as described in the Overview above.
STEP 2 To add a new operation, click Add.
STEP 3 Enter the following fields:
• Operation Number—Enter an unused number.
• Operation State—Select one of the following options:
- Pending—Operation is not activated.
- Scheduled—Operation is activated.
ICMP-Echo Parameters
• Operation Target—Select how the operation target is defined:
- By IP—Enter the operation target’s IP address.
