Administration
Stack Management
65 Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x
5
If Auto Detection is selected, the device detects console speed automatically.
When Auto Detection is not enabled, the console port speed is automatically set to the last
speed that was set manually at (115,200 by default).
When Auto Detection is enabled but the console baud-rate has not yet been discovered, the
system uses speed 115,200 for displaying text (for example, the boot-up information).
After Auto Detection is enabled in the Console Settings page, it can be activated by connecting
the console to the device and pressing the Enter key twice. The device detects the baud rate
automatically.
To enable Auto Detection or to manually set the baud rate of the console:
STEP 1 Click Administration > Console Settings.
STEP 2 Select one of the following options in the Console Port Baud Rate field:
• Auto Detection—The console baud rate is detected automatically.
• Static—Select one of the available speeds.
STEP 3 Click Apply.
Stack Management
See Administration: Stack Management.
User Accounts
The User Accounts page enables entering additional users that are permitted to access to the
device (read-only or read-write) or changing the passwords of existing users.
After adding a level 15 user (as described below), the default user is removed from the system.
NOTE It is not permitted to delete all users. If all users are selected, the Delete button is disabled.
