D-Link DSL-G225 User Manual

97D-Link DSL-G225 Wireless N300 ADSL2+/VDSL2 Modem Router User Manual
Section 4 - Conguration
IP Address
ACCESS CONTROL  IP ADDRESSES
Enable Access
Control Mode:
Check to enable access to local management services.
Add: Pressing this button will make the IP Address dialog box appear.
Delete: Check the check box next to an IP address and press the delete button
to remove an IP from the Access Control List.
Warning: If the last IP Address is Deleted from the Access Control List
and still have Access Control enabled, you will be unable to access
the web conguration utility and will need to reset the router.
IP ADDRESSES
IP Address: Enter a desired IP Address to add to the Access Control List.
From this page you can limit access to the router management services to the following list of IP addresses.
Click Apply to add the IP Address to the Access Control List.

D-Link DSL-G225 Specifications

Power

input voltage	100~240 V
input frequency	50~60 Hz
output voltage	DC 12 V

Operating Environment

operating temperature	0 to 40 °C
non-operating temperature	-20 to 65 °C
operating humidity	0% - 90% non-condensing

Weight and Dimensions

dimensions	131.5 x 74.3 x 185.4 mm
weight	285 grams
