D-Link DSL-G225 User Manual

17D-Link DSL-G225 Wireless N300 ADSL2+/VDSL2 Modem Router User Manual
Section 3 - Getting Started
This step of the wizard allows you to congure your Internet connection type.
If you have an ADSL connection, select ADSL. If you have a VDSL connection,
select VDSL. If you have a cable or NBN Fiber connection and are connecting
via the WAN port, select ETH WAN.
Step 3: Setup Internet Connection
If you selected Dynamic IP or Bridged, click Next to continue.
If you selected ETH WAN, select and congure the Internet Protocol used by
your ISP: Dynamic IP, Static IP, PPPoE, or Bridged.
If you selected ADSL or VDSL, choose your Country and Internet Service
Provider (ISP) from the drop-down menu. The necessary settings will
automatically populate.
If you cannot nd your country or ISP, select Others. You will need to enter
the data provided by your ISP manually. Select the Protocol used by your ISP:
Dynamic IP, Static IP, PPPoE, PPPoA, or Bridged. Also select the Connection
Type, and input the VPI and VCI settings for ADSL, or VLAN and VLAN ID
for VDSL.

D-Link DSL-G225 Specifications

Power

input voltage	100~240 V
input frequency	50~60 Hz
output voltage	DC 12 V

Operating Environment

operating temperature	0 to 40 °C
non-operating temperature	-20 to 65 °C
operating humidity	0% - 90% non-condensing

Weight and Dimensions

dimensions	131.5 x 74.3 x 185.4 mm
weight	285 grams
