91
 e.sy Other e.sybox pump for operation in a pump set
 composed of max 4 elements
 COM PWM Com communication control unit
 TERM PWM Term remote control terminal
 I/O e.sybox I/O input output control unit
 RPR Remote pressure sensor
 DEV Any other compatible devices
Connections menu
The icons of the various connected devices are displayed with below an
identifying acronym and the respective reception power.
$QLFRQOLWZLWKD¿[HGOLJKWPHDQVWKDWWKHGHYLFHLVFRQQHFWHGDQGZRUN-
LQJFRUUHFWO\DVWURNHGWKURXJKLFRQPHDQVWKHGHYLFHLVFRQ¿JXUHGDV
part of the network but is not found.
Pressing “+” or “-” allows you to select a device that is already connected
(function active on release) making the respective icon appear in reverse;
when the device is selected, a description of the selected device appears
underlined.
All the devices present over the air are not displayed on this
page but only the devices that have been associated with our
network.
Seeing only the devices in your own network allows the opera-
tion of several similar networks existing within the radius of
action of the wireless without creating ambiguity; in this way
the user does not see the elements that do not belong to his
pumping system.
From this menu page it is possible to associate and disassociate an ele-
ment from your personal wireless network.
When the machine starts the AS menu item does not show any connec-
tion because no device is associated. Only an action by the operator can
allow devices to be added or removed with the operations of association
and disassociation.
91
$'$GGUHVVFRQ¿JXUDWLRQ
7KLVLVVLJQL¿FDQWRQO\LQDPXOWLSXPSFRQQHFWLRQ6HWWKHFRPPXQL-
cation address to be assigned to the device. The possible values are:
automatic (default) or manually assigned address.
7KHDGGUHVVHVVHWPDQXDOO\FDQKDYHYDOXHVIRUPWR7KHFRQ¿JXUD-
tion of the addresses must be the same for all the devices that make up
the group: either all automatic or all manual. Setting the same addresses
is not allowed.
Both in the case of assigning mixed addresses (some manual and some
automatic) and in the case of duplicate addresses, an error signal is
JLYHQ7KHHUURUVLJQDOLVJLYHQE\GLVSOD\LQJDÀDVKLQJ(LQWKHSODFHRI
the machine address.
If the chosen assignment is automatic, whenever the system is switched
on addresses are assigned that may be different from the previous time,
but this does not affect correct operation.
7.5.4 - MS: Measuring system
Set the measuring system, choosing between metric and imperial units.
The quantities displayed are shown in Table 10.
Units of measurement displayed
Quantity Metric units Imperial units
Pressure bar psi
Temperature °C °F
Flow rate l / min gal / min
7.5.5 - AS: Association of devices
Allows connection/disconnection with the following devices
Table 13: Measuring system
ENGLISH
GB
