not be possible to change them.
When the password (PW) is “0” all the parameters are unlocked and can
be edited.
:KHQDSDVVZRUGLVXVHGYDOXHRI3:GLIIHUHQWIURPDOOPRGL¿FDWLRQV
DUHEORFNHGDQG³;;;;´LVGLVSOD\HGRQWKHSDJH3:
If the password is set it allows to navigate through all the pages, but at
any attempt to edit a parameter a pop-up appears, asking you to type in
the password. When the correct password is typed in the parameters are
unlocked and can be edited for 10’.
If you want to cancel the password timer, just go to page PW and hold
down + and – together for 2”.
When the correct password is typed in a padlock is shown opening, while
LIWKHZURQJSDVVZRUGLVJLYHQDÀDVKLQJSDGORFNDSSHDUV
If the wrong password is typed in more than 10 times the same wrong
password padlock appears with inverted colours and no password can
be accepted until the appliance has been switched off and on again. After
resetting the factory values the password is set back at “0”.
Each change of the password takes effect when Mode or Set is pressed
and each subsequent change of a parameter implies typing in the new
password again (e.g. the installer makes all the settings with the default
PW value = 0 and lastly sets the PW so as to be sure that the machine is
already protected without any further action).
If the password is lost there are 2 possibilities for editing the parameters
of the device:
0DNHDQRWHRIWKHYDOXHVRIDOOWKHSDUDPHWHUVUHVHWWKH
device with the factory values, see paragraph 0. The reset
operation cancels all the parameters of the device, including the
password.
0DNHDQRWHRIWKHQXPEHUSUHVHQWRQWKHSDVVZRUGSDJH
send a mail with this number to your service centre, in a few
days you will be sent the password to unlock the device.
99
7.8.2 - O2: Setting output 2 function
Output 2 communicates the motor running status. The output allows the
use of a normally open clean contact.
The values and functions indicated in Table 18 are associated with the
parameter O2.
&RQ¿JXUDWLRQRIWKHIXQFWLRQVDVVRFLDWHGZLWKWKHRXWSXWV
2XWSXWFRQ¿-
guration
OUT1 OUT2
Activation
condition
Output contact
status
Activation
condition
Output contact
status
0
No associated
function
Contact always
open
No associated
function
Contact always
open
1
No associated
function
Contact always
closed
No associated
function
Contact always
closed
2
Presence
of blocking
errors
In the case of
blocking errors the
contact closes
Output activa-
tion in case of
blocking errors
When the motor is
running the contact
closes
3
Presence
of blocking
errors
In the case of
blocking errors the
contact opens
Output activa-
tion in case of
blocking errors
When the motor is
running the contact
opens
7.9 - RF: Fault and warning reset
Holding down the + and – keys together for at least 2 seconds deletes
the history of faults and warnings. The number of faults present in the log
is indicated under the symbol RF (max 64).
The log can be viewed from the MONITOR menu on page FF.
7.10 - PW: Change password
The device has a password-enabled protection system. If a password is
set, the parameters of the device will be accessible and visible but it will
7DEOH&RQ¿JXUDWLRQRIWKHRXWSXWV
