Parameter Function
period and go to Storage-> Schedule to set current channel as
schedule record.
Record Delay System can delay the record for specified time after alarm ended.
The value ranges from 10s to 300s.
Alarm out Enable alarm activation function. You need to select alarm output
port so that system can activate corresponding alarm device when
an alarm occurs.
Latch System can delay the alarm output for specified time after an
alarm ended. The value ranges from 1s to 300s.
Show
message
System can pop up a message to alarm you in the local host
screen if you enabled this function.
Buzzer Check the box here to enable this function. The buzzer beeps
when an alarm occurs.
Alarm upload System can upload the alarm signal to the centre (Including alarm
centre.
Message When 3G network connection is OK, system can send out a
message when motion detect occurs.
Send Email If you enabled this function, System can send out an email to alert
you when an alarm occurs.
Tour You need to click setup button to select tour channel. System
begins 1-wiindow or multiple-window tour display among the
channel(s) you set to record when an alarm occurs. See Figure
4-54.
PTZ
Activation
Here you can set PTZ movement when an alarm occurs. Such as
go to preset X. See Figure 4-53.
Snapshot Click setup button to select snapshot channel. See Figure 4-55.
4.8.3.1.2 Video Loss
From main window->Setup->Event->Video detect->Video loss, the video loss interface is shown as in
Figure 4-56.
Please note video loss does not support anti-dither, sensitivity, region setup. For rest setups, please refer
to chapter 4.8.3.1.1 motion detect for detailed information.
173
