4.8.5.2.2 Tou r
From main menu->Setup->System->Display->Tour, the tour interface is shown as in Figure 4-91. Here
you can set tour interval, split mode, motion detect tour and alarm tour mode.
Figure 4-91
Please refer to the following sheet for detailed information.
Parameter Function
Enable tour
Check the box here to enable tour function.
Interval
Here is for you to adjust transparency. The value ranges from 5 to
120s. The default setup is 5s.
Split
Here you can set window mode and channel group. System can
support 1/4/8/9/16/25/36-window according to device channel
Motion
tour/Alarm
tour
Here you can set motion detect tour/alarm tour window mode.
System supports 1/8-window now.
4.8.5.3 RS232
From main menu->Setup->System->RS232, the RS232 interface is shown as in Figure 4-92.
196
