SiUS091601EA Troubleshooting with LED
Part 6 Service Diagnosis 110
FDMQ series with BRC082A43
For wireless remote controller, a receiver is installed. When the error occurs, the operation lamp on
the receiver blinks.
R4003517
2.2 Outdoor Unit
The outdoor unit has one green LED (LED A) on the PCB. When the microcomputer works in order,
the LED A blinks. However, the LED A turns OFF while the standby electricity saving function is
activated and the power supply is OFF.
Refer to page 34, 36, 38, 39 for the location of LED A.
Operation lamp
(red)
To Next Page
