Daikin FDMQ-R Series Service Manual

Field Settings for FTX, FVXS Series SiUS091601EA
209 Part 7 Trial Operation and Field Settings
Caution
Caution
Reference
Replace the PCB if you cut a jumper unintentionally.
Jumpers are necessary for electronic circuit. Improper operation may occur if you cut any of them.
Replace the remote controller if you cut a jumper unintentionally
.
Jumpers are necessary for electronic circuit. Improper operation may occur if you cut any of them.
4.3 Jumper and Switch Settings
Jumper for FTX18/24UVJU, FVXS series
Switch for FVXS series
For the location of the jumper and the switch, refer to the following pages.
FTX18/24UVJU: page 26
FVXS: page 28
Jumper
on indoor
unit PCB
Function
When connected
(factory setting)
When cut
JB
Fan speed setting when
compressor stops for
thermostat OFF.
(effective only at cooling
operation)
Fan speed setting;
Remote controller setting
The fan stops.
JC
Power failure recovery
function
Auto-restart The unit does not
resume operation after
recovering from a power
failure. Timer settings
are cleared.
Switch
on indoor unit
PCB
Function
OFF
(factory setting)
ON
SW2-4
Upward airflow limit
setting
Exposed or half
embedded installation
Set the switch to ON
position when you install
the indoor unit
embedded in the wall to
avoid condensation.
