Daikin FDMQ-R Series Service Manual

Functions for FDMQ Series SiUS091601EA
73 Part 4 Functions and Control
 Enabling or disabling the schedule
R4003458
3.5 Drain Pump Control
Normal Operation
 The float switch is ON in normal operation.
 When cooling operation starts (thermostat ON), the drain pump turns ON simultaneously.
 After the thermostat turns OFF, the drain pump continues to operate.
1
2
3
Display the schedule screen.
Press buttons to select
Enable / Disable
on the schedule
screen.
Press Menu/OK button to display the
enable/disable screen.
Press buttons to select
Enable
or
Disable on the enable/disable
screen.
Press Menu/OK button after selecting
the item. The confirmation screen is
displayed.
Press buttons to select
Yes on the
confirmation screen.
Pressing Menu/OK button confirms the
enable/disable setting for the schedule
and takes you back to the basic screen.
Float switch
Error display
Thermostat
(running)
OFF
OFF
ON
ON
ON
OFF
Drain pump
ON
OFF
(R24037)
