Danfoss VLT AutomationDrive FC 302 Service Guide

10.2.14 Inrush Card
To remove or reinstall the inrush card, use the following
steps. Refer to Illustration 10.9.
Disassembly
1. Remove the DC bus rails. Refer to
chapter 10.2.13 DC Bus Rails.
2. Unplug the cables from the following connectors
on the inrush card:
2a MK1800
2b MK1802
3. Remove 5 screws (T20) from the inrush card.
4. Remove the inrush card from the drive.
Reassembly
Tighten hardware according to chapter 14.1 Fastener Torque
Ratings.
1. Position the inrush card in the drive.
2. Fasten 5 screws (T20) in the inrush card.
3. Fasten the cables to the following connectors on
the inrush card:
3a MK1800
3b MK1802
4. Replace the DC bus rails. Refer to
chapter 10.2.13 DC Bus Rails.
D1h/D3h/D5h/D6h/J8 Drive Di...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
148 Danfoss A/S © 02/2019 All rights reserved. MG94A502
1010

Danfoss VLT AutomationDrive FC 302 Specifications

General

Category	DC Drives
Control Method	Flux Vector Control
Communication Options	CANopen, PROFIBUS
Cooling	Forced convection
Enclosure	IP20, IP21, IP55, IP66
Protection Class/Rating	IP20
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overtemperature, Short Circuit
Approvals	CE, UL, cUL
Ambient Temperature	-10°C to +50°C
Storage Temperature	-40°C to +70°C
Relative Humidity	5% to 95% (non-condensing)
Output Voltage	0 V to Input Voltage
