Danfoss VLT AutomationDrive FC 302 Service Guide

3.5 Enclosure Size Denitions
Power
rating
Drive type Enclosure size Enclosure size with
extended options cabinet
Number of drive modules
N55K H D1h/D3h – –
N75K H D1h/D3h – –
N90K H D2h/D4h – –
N110 H D2h/D4h – –
N150 H D2h/D4h – –
N160 H D2h/D4h – –
Table 3.4 200–240 V AC (T2) Voltage Rating for FC 102, FC 103, and FC 202
Power
rating
Drive type Enclosure size Enclosure size with
extended options cabinet
Number of drive modules
N45K H D1h/D3h – –
N55K H D1h/D3h – –
N75K H D2h/D4h – –
N90K H D2h/D4h – –
N110 H D2h/D4h – –
N150 H D2h/D4h – –
Table 3.5 200–240 V AC (T2) Voltage Rating for FC 302
Product Overview Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 17
3 3

Danfoss VLT AutomationDrive FC 302 Specifications

General

Category	DC Drives
Control Method	Flux Vector Control
Communication Options	CANopen, PROFIBUS
Cooling	Forced convection
Enclosure	IP20, IP21, IP55, IP66
Protection Class/Rating	IP20
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overtemperature, Short Circuit
Approvals	CE, UL, cUL
Ambient Temperature	-10°C to +50°C
Storage Temperature	-40°C to +70°C
Relative Humidity	5% to 95% (non-condensing)
Output Voltage	0 V to Input Voltage
