Danfoss VLT FC 302 User Manual

11 Specifications
11.1 Power-Dependent Specifications
11.1.1 Mains Supply 3x380-480 V AC
P160 P200 P250
Normal Overload =110% current for 60 s NO NO NO
Typical shaft output at 400 V [kW] 160 200 250
Typical shaft output at 460 V [hp] 250 300 350
Typical shaft output at 480 V [kW] 200 250 315
Enclosure IP21/54 D13
Output current
Continuous (at 400 V) [A] 315 395 480
Intermittent (60 s overload) (at 400 V) [A] 347 435 528
Continuous (at 460/480 V) [A] 302 361 443
Intermittent (60 s overload) (at 460/480 V)
[A]
332 397 487
Continuous kVA (at 400 V) [kVA] 218 274 333
Continuous kVA (at 460 V) [kVA] 241 288 353
Continuous kVA (at 480 V) [kVA] 262 313 384
Max. Input current
Continuous (at 400 V) [A] 304 381 463
Continuous (at 460/480 V) [A] 291 348 427
Max. pre-fuses
1)
[A]
400 500 630
Max. cable size
Motor (mm
2
/AWG
2)
)
2x185 (2x300 mcm)
Mains (mm
2
/AWG
2)
)
Brake (mm
2
/AWG
2)
)
Total LHD loss 400 V AC [kW] 8868 10527 11751
Total back channel loss 400 V AC [kW] 7318 8903 10033
Total filter loss 400 V AC [kW] 4954 5714 6234
Total LHD loss 460 V AC [kW] 9059 10192 11706
Total back channel loss 460 V AC [kW] 7123 8209 9635
Total filter loss 460 V AC [kW] 5279 5819 6681
Weight, enclosure IP21, IP54 [kg] 380 406
Efficiency
4)
0.96
Output frequency [Hz] 0-800
Heatsink overtemp. trip [°C] 105
Power card ambient trip [°C] 85
*High overload = 160% torque during 60 s; Normal overload = 110% torque during 60 s
Table 11.1 Mains Supply 3x380-480 V AC
Specifications Operating Instructions
MG37A202 Danfoss A/S © Rev. 2014-07-29 All rights reserved. 139
