Danfoss VLT HVAC Basic Drive FC 101 Programming Guide

5.1.2 0-** Operation/Display
Par.
No. #
Parameter description Default value 2-set-up Change during
operation
Conversion
index
Type
0-0* Basic Settings
0-01 Language [0] English 1 set-up TRUE – Uint8
0-03 Regional Settings [0] International 1 set-up FALSE – Uint8
0-04 Operating State at Power-up [0] Resume All set-ups FALSE – Uint8
0-06 GridType ExpressionLimit 1 set-up FALSE – Uint8
0-07 Auto DC Braking [1] On 1 set-up FALSE – Uint8
0-1* Set-up Operations
0-10 Active Set-up [1] Set-up 1 1 set-up FALSE – Uint8
0-11 Programming Set-up [9] Active Set-up 1 set-up FALSE – Uint8
0-12 Link Setups [20] Linked All set-ups FALSE – Uint8
0-3* LCP Custom Readout
0-30 Custom Readout Unit [1] % 1 set-up FALSE – Uint8
0-31 Custom Readout Min Value 0 CustomReadoutUnit 1 set-up TRUE -2 Int32
0-32 Custom Readout Max Value 100 CustomReadoutUnit 1 set-up TRUE -2 Int32
0-37 Display Text 1 0 N/A 1 set-up FALSE 0 VisStr[21]
0-38 Display Text 2 0 N/A 1 set-up FALSE 0 VisStr[26]
0-39 Display Text 3 0 N/A 1 set-up FALSE 0 VisStr[26]
0-4* LCP Keypad
0-40 [Hand on] Key on LCP [1] Enabled All set-ups FALSE – Uint8
0-42 [Auto on] Key on LCP [1] Enabled All set-ups FALSE – Uint8
0-44 [O/Reset] Key on LCP [1] Enabled All set-ups FALSE – Uint8
0-5* Copy/Save
0-50 LCP Copy [0] No copy 1 set-up FALSE – Uint8
0-51 Set-up Copy [0] No copy 1 set-up FALSE – Uint8
0-6* Password
0-60 Main Menu Password 0 N/A 1 set-up FALSE 0 Uint16
0-61 Access to Main Menu w/o Password [0] Full access 1 set-up FALSE – Uint8
5.1.3 1-** Load and Motor
Par.
No. #
Parameter description Default value 2-set-up Change during
operation
Conversion
index
Type
1-0* General Settings
1-00 Conguration Mode [0] Open Loop All set-ups FALSE – Uint8
1-01 Motor Control Principle [1] VVC+ All set-ups FALSE – Uint8
1-03 Torque Characteristics [1] Variable Torque All set-ups FALSE – Uint8
1-06 Clockwise Direction [0] Normal 1 set-up FALSE – Uint8
1-08 Motor Control Bandwidth ExpressionLimit All set-ups FALSE – Uint8
1-1* Motor Selection
1-10 Motor Construction [0] Asynchron All set-ups FALSE – Uint8
1-11 Motor Selection [0] Default Motor Selection All set-ups FALSE – Uint8
1-14 Damping Gain 120% All set-ups FALSE 0 Int16
1-15 Low Speed Filter Time Const. ExpressionLimit All set-ups FALSE -2 Uint16
1-16 High Speed Filter Time Const. ExpressionLimit All set-ups FALSE -2 Uint16
1-17 Voltage lter time const. ExpressionLimit All set-ups FALSE -3 Uint16
1-2* Motor Data
1-20 Motor Power ExpressionLimit All set-ups FALSE – Uint8
1-22 Motor Voltage ExpressionLimit All set-ups FALSE 0 Uint16
1-23 Motor Frequency ExpressionLimit All set-ups FALSE 0 Uint16
1-24 Motor Current ExpressionLimit All set-ups FALSE -2 Uint32
Parameter Lists
VLT
®
HVAC Basic Drive FC 101
106 Danfoss A/S © 04/2018 All rights reserved. MG18B502
