Danfoss VLT HVAC Basic Drive FC 101 Programming Guide

Par.
No. #
Parameter description Default value 2-set-up Change
during
operation
Conversion
index
Type
14-44 d-axis current optimization for IPM 100% All set-ups FALSE 0 Uint8
14-5* Environment
14-51 DC-Link Voltage Compensation [1] On All set-ups FALSE – Uint8
14-52 Fan Control [0] Auto 1 set-up FALSE – Uint8
14-53 Fan Monitor [1] Warning 1 set-up FALSE – Uint8
14-55 Output Filter [0] No Filter 1 set-up FALSE – Uint8
14-6* Auto Derate
14-61 Function at Inverter Overload [0] Trip All set-ups FALSE – Uint8
14-63 Min Switch Frequency [2] 2.0 kHz 1 set-up FALSE – Uint8
14-64
Dead Time Compensation Zero Current
Level [0] Disabled All set-ups FALSE – Uint8
14-65 Speed Derate Dead Time Compensation ExpressionLimit All set-ups FALSE 0 Uint16
14-9* Fault Settings
14-90 Fault Level [3] Trip lock All set-ups FALSE – Uint8
5.1.12 15-** Drive Information
Par. No. # Parameter description Default value 2-set-up Change
during
operation
Conversion
index
Type
15-0* Operating Data
15-00 Operating hours 0 h All set-ups FALSE 74 Uint32
15-01 Running hours 0 h All set-ups FALSE 74 Uint32
15-02 kWh counter 0 kWh All set-ups FALSE 75 Uint32
15-03 Power up's 0 N/A All set-ups FALSE 0 Uint32
15-04 Over temp's 0 N/A All set-ups FALSE 0 Uint16
15-05 Over volt's 0 N/A All set-ups FALSE 0 Uint16
15-06 Reset kWh counter [0] Do not reset All set-ups FALSE – Uint8
15-07 Reset running hours counter [0] Do not reset All set-ups FALSE – Uint8
15-3* Alarm Log
15-30 Alarm log: error code 0 N/A All set-ups FALSE 0 Uint8
15-31 Internal fault reason 0 N/A 1 set-up FALSE 0 Int16
15-4* Drive Identication
15-40 FC type 0 N/A 1 set-up FALSE 0 VisStr[6]
15-41 Power section 0 N/A 1 set-up FALSE 0 VisStr[20]
15-42 Voltage 0 N/A 1 set-up FALSE 0 VisStr[20]
15-43 Software version 0 N/A 1 set-up FALSE 0 VisStr[20]
15-44 Ordered typecode 0 N/A 1 set-up FALSE 0 VisStr[40]
15-45 Actual typecode string 0 N/A All set-ups FALSE 0 VisStr[40]
15-46 Drive ordering no 0 N/A 1 set-up FALSE 0 VisStr[8]
15-48 LCP ID number 0 N/A 1 set-up FALSE 0 VisStr[21]
15-49 SW ID control card 0 N/A 1 set-up FALSE 0 VisStr[21]
15-50 SW ID power card 0 N/A 1 set-up FALSE 0 VisStr[21]
15-51 Drive serial number 0 N/A 1 set-up FALSE 0 VisStr[10]
15-53 Power card serial number 0 N/A 1 set-up FALSE 0 VisStr[20]
15-59 CSIV lename 0 N/A 1 set-up FALSE – VisStr[16]
Parameter Lists Programming Guide
MG18B502 Danfoss A/S © 04/2018 All rights reserved. 113
5 5
