Danfoss VLT HVAC Basic Drive FC 101 Programming Guide

5.1.13 16-** Data Readouts
Par. No. # Parameter description Default value 2-set-up Change
during
operation
Conversion
index
Type
16-0* General Status
16-00 Control word 0 N/A 1 set-up FALSE 0 Uint16
16-01 Reference [unit] 0 1 set-up FALSE -3 Int32
16-02 Reference [%] 0% 1 set-up FALSE -1 Int16
16-03 Status word 0 N/A 1 set-up FALSE 0 Uint16
16-05 Main actual value [%] 0% 1 set-up FALSE -2 Int16
16-09 Custom readout 0 CustomReadoutUnit 1 set-up FALSE -2 Int32
16-1* Motor Status
16-10 Power [kW] 0 kW 1 set-up FALSE -3 Uint32
16-11 Power [hp] 0 hp 1 set-up FALSE -3 Uint32
16-12 Motor voltage 0 V 1 set-up FALSE -1 Uint32
16-13 Frequency 0 Hz 1 set-up FALSE -1 Uint32
16-14 Motor current 0 A 1 set-up FALSE -2 Uint16
16-15 Frequency [%] 0% 1 set-up FALSE -1 Uint16
16-16 Torque [Nm] 0 Nm All set-ups FALSE 0 Int32
16-17 Speed [RPM] 0 RPM 1 set-up FALSE 0 Int32
16-18 Motor thermal 0% 1 set-up FALSE 0 Uint8
16-22 Torque [%] 0% All set-ups FALSE 0 Int16
16-3* Drive Status
16-30 DC link voltage 0 V 1 set-up FALSE 0 Uint32
16-34 Heatsink temperature 0 °C 1 set-up FALSE 100 Int8
16-35 Inverter thermal 0% 1 set-up FALSE 0 Uint8
16-36 Inverter nominal current 0 A 1 set-up FALSE -2 Uint16
16-37 Inverter maximum current 0 A 1 set-up FALSE -2 Uint16
16-38 SL controller state 0 N/A 1 set-up FALSE 0 Uint8
16-5* Ref. & Feedb.
16-50 External reference 0% 1 set-up FALSE -1 Int16
16-52 Feedback[Unit] 0 1 set-up FALSE -3 Int32
16-54 Feedback 1 [Unit] 0 All set-ups FALSE -3 Int32
16-55 Feedback 2 [Unit] 0 All set-ups FALSE -3 Int32
16-6* Inputs & Outputs
16-60 Digital input 0 N/A 1 set-up FALSE 0 Uint16
16-61 Terminal 53 setting [0] Current mode 1 set-up FALSE – Uint8
16-62 Analog input AI53 1 N/A 1 set-up FALSE -2 Uint16
16-63 Terminal 54 setting [0] Current mode 1 set-up FALSE – Uint8
16-64 Analog input AI54 1 N/A 1 set-up FALSE -2 Uint16
16-65 Analog output AO42 [mA] 0 mA 1 set-up FALSE -2 Uint16
16-66 Digital output 0 N/A 1 set-up FALSE 0 VisStr[4]
16-67 Pulse input #29 [Hz] 0 N/A All set-ups FALSE 0 Int32
16-71 Relay output [bin] 0 N/A 1 set-up FALSE 0 Uint16
16-72 Counter A 0 N/A 1 set-up FALSE 0 Int16
16-73 Counter B 0 N/A 1 set-up FALSE 0 Int16
16-79 Analog output AO45 0 mA 1 set-up FALSE -2 Uint16
16-8* Fieldbus & FC Port
16-86 FC port REF 1 0 N/A 1 set-up FALSE 0 Int16
16-9* Diagnosis Readouts
16-90 Alarm word 0 N/A 1 set-up FALSE 0 Uint32
16-91 Alarm word 2 0 N/A 1 set-up FALSE 0 Uint32
Parameter Lists
VLT
®
HVAC Basic Drive FC 101
114 Danfoss A/S © 04/2018 All rights reserved. MG18B502
55
