Danfoss VLT HVAC Basic Drive FC 101 Programming Guide

5.1.16 22-** Appl. Functions
Par. No. # Parameter description Default value 2-set-up Change
during
operation
Conversion
index
Type
22-0* Miscellaneous
22-01 Power Filter Time 0.50 s All set-ups FALSE -2 Uint16
22-02 Sleep mode CL control mode [0] Normal All set-ups FALSE – Uint8
22-2*
22-23 No-Flow Function [0] O All set-ups FALSE – Uint8
22-24 No-Flow Delay 10 s All set-ups FALSE 0 Uint16
22-3*
22-30 No-Flow Power 0 kW All set-ups FALSE 0 Uint32
22-31 Power Correction Factor 100 % All set-ups FALSE 0 Uint16
22-33 Low Speed [Hz] 0 Hz All set-ups FALSE 0 Uint16
22-34 Low Speed Power [kW] 0 kW All set-ups FALSE 0 Uint32
22-37 High Speed [Hz] 0 Hz All set-ups FALSE 0 Uint16
22-38 High Speed Power [kW] 0 kW All set-ups FALSE 0 Uint32
22-4* Sleep Mode
22-40 Minimum run time 10 s All set-ups FALSE 0 Uint16
22-41 Minimum sleep time 10 s All set-ups FALSE 0 Uint16
22-43 Wake-up speed [Hz] 10 N/A All set-ups FALSE -1 Uint16
22-44
Wake-up reference/feedback
dierence 10% All set-ups FALSE 0 Uint8
22-45 Setpoint boost 0% All set-ups FALSE 0 Int8
22-46 Maximum boost time 60 s All set-ups FALSE 0 Uint16
22-47 Sleep speed [Hz] 0 N/A All set-ups FALSE -1 Uint16
22-48 Sleep delay time 0 s All set-ups FALSE 0 Uint16
22-49 Wake-up delay time 0 s All set-ups FALSE 0 Uint16
22-6* Broken Belt Detection
22-60 Broken belt function [0] O All set-ups FALSE - Uint8
22-61 Broken belt torque 10% All set-ups FALSE 0 Uint8
22-62 Broken belt delay 10 s All set-ups FALSE 0 Uint16
22-8* Flow Compensation
22-80 Flow Compensation [0] Disabled All set-ups FALSE – Uint8
22-81 Square-linear Curve Approximation 100 % All set-ups FALSE 0 Uint8
22-82 Work Point Calculation [0] Disabled All set-ups FALSE – Uint8
22-84 Speed at No-Flow [Hz] Expressionlimit (50.0) All set-ups FALSE -1 Uint16
22-86 Speed at Design Point [Hz] Expressionlimit (50.0) All set-ups FALSE -1 Uint16
22-87 Pressure at No-Flow Speed 0 N/A All set-ups FALSE 0 Uint32
22-88 Pressure at Rated Speed 4999.000 N/A All set-ups FALSE -3 Uint32
22-89 Flow at Design Point 0 N/A All set-ups FALSE 0 Int32
Parameter Lists
VLT
®
HVAC Basic Drive FC 101
116 Danfoss A/S © 04/2018 All rights reserved. MG18B502
