5.1.10 13-** Smart Logic
Par.
No. #
Parameter description Default value 2-set-up Change
during
operation
Conversion
index
Type
13-0* SLC Settings
13-00 SL Controller Mode [0] O 1 set-up FALSE – Uint8
13-01 Start Event [39] Start command 1 set-up FALSE – Uint8
13-02 Stop Event [40] Drive stopped 1 set-up FALSE – Uint8
13-03 Reset SLC [0] Do not reset SLC 1 set-up FALSE – Uint8
13-1* Comparators
13-10 Comparator Operand [0] Disabled 1 set-up FALSE – Uint8
13-11 Comparator Operator [1] Approx.Equal (~) 1 set-up FALSE – Uint8
13-12 Comparator Value 0 N/A 1 set-up FALSE -3 Int32
13-2* Timers
13-20 SL Controller Timer 0 s 1 set-up FALSE -2 Uint32
13-4* Logic Rules
13-40 Logic Rule Boolean 1 [0] False 1 set-up FALSE – Uint8
13-41 Logic Rule Operator 1 [0] Disabled 1 set-up FALSE – Uint8
13-42 Logic Rule Boolean 2 [0] False 1 set-up FALSE – Uint8
13-43 Logic Rule Operator 2 [0] Disabled 1 set-up FALSE – Uint8
13-44 Logic Rule Boolean 3 [0] False 1 set-up FALSE – Uint8
13-5* States
13-51 SL Controller Event [0] False 1 set-up FALSE – Uint8
13-52 SL Controller Action [0] Disabled 1 set-up FALSE – Uint8
5.1.11 14-** Special Functions
Par.
No. #
Parameter description Default value 2-set-up Change
during
operation
Conversion
index
Type
14-0* Inverter Switching
14-01 Switching Frequency ExpressionLimit All set-ups FALSE – Uint8
14-03 Overmodulation [0] O All set-ups FALSE – Uint8
14-07 Dead Time Compensation Level ExpressionLimit All set-ups FALSE 0 Uint8
14-08 Damping Gain Factor ExpressionLimit All set-ups FALSE 0 Uint8
14-09 Dead Time Bias Current Level ExpressionLimit All set-ups FALSE 0 Uint8
14-1* Mains On/O
14-10 Mains Failure [0] No function All set-ups FALSE – Uint8
14-11 Mains Voltage at Mains Fault ExpressionLimit All set-ups FALSE 0 Uint16
14-12 Function at Mains Imbalance [0] Trip 1 set-up FALSE – Uint8
14-2* Reset Functions
14-20 Reset Mode [0] Manual reset All set-ups FALSE – Uint8
14-21 Automatic Restart Time 10 s All set-ups FALSE 0 Uint16
14-22 Operation Mode [0] Normal operation 1 set-up FALSE – Uint8
14-27 Action At Inverter Fault [1] Warning All set-ups FALSE – Uint8
14-29 Service Code 0 N/A 1 set-up FALSE 0 Uint32
14-3* Current Limit Ctrl.
14-30 Current Lim Ctrl, Proportional Gain 100% All set-ups FALSE 0 Uint16
14-31 Current Lim Ctrl, Integration Time ExpressionLimit All set-ups FALSE -3 Uint16
14-32 Current Lim Ctrl, Filter Time ExpressionLimit All set-ups FALSE -4 Uint16
14-4* Energy Optimization
14-40 VT Level 90% All set-ups FALSE 0 Uint8
14-41 AEO Minimum Magnetisation 66% All set-ups FALSE 0 Uint8
Parameter Lists
VLT
®
HVAC Basic Drive FC 101
112 Danfoss A/S © 04/2018 All rights reserved. MG18B502
