5.1.9 8-** Comm. and Options
Par. No. # Parameter description Default value 2-set-up Change
during
operation
Conversion
index
Type
8-0* General Settings
8-01 Control site [0] Digital and ctrl.word All set-ups FALSE – Uint8
8-02 Control source [1] FC Port All set-ups FALSE – Uint8
8-03 Control timeout time 1 s 1 set-up FALSE -1 Uint16
8-04 Control timeout function [0] O 1 set-up FALSE – Uint8
8-3* FC Port Settings
8-30 Protocol [0] FC 1 set-up FALSE – Uint8
8-31 Address 1 N/A 1 set-up FALSE 0 Uint8
8-32 Baud rate ExpressionLimit 1 set-up FALSE – Uint8
8-33 Parity/stop bits ExpressionLimit 1 set-up FALSE – Uint8
8-35 Minimum response delay 0.01 s 1 set-up FALSE -3 Uint16
8-36 Maximum response delay ExpressionLimit 1 set-up FALSE -3 Uint16
8-37 Maximum inter-char delay 0.025 s 1 set-up FALSE -3 Uint16
8-4* FC MC protocol set
8-42 PCD write conguration [0] None All set-ups TRUE – Uint8
8-43 PCD read conguration [0] None 1 set-up TRUE – Uint8
8-5* Digital/Bus
8-50 Coasting select [3] Logic OR All set-ups FALSE – Uint8
8-51 Quick stop select [3] Logic OR All set-ups FALSE – Uint8
8-52 DC brake select ExpressionLimit All set-ups FALSE – Uint8
8-53 Start select [3] Logic OR All set-ups FALSE – Uint8
8-54 Reversing select [0] Digital input All set-ups FALSE – Uint8
8-55 Set-up select [3] Logic OR All set-ups FALSE – Uint8
8-56 Preset reference select [3] Logic OR All set-ups FALSE – Uint8
8-7* BACnet
8-70 BACnet device instance 1 N/A 1 set-up FALSE 0 Uint32
8-72 MS/TP maximum masters 127 N/A 1 set-up FALSE 0 Uint8
8-73 MS/TP maximum info frames 1 N/A 1 set-up FALSE 0 Uint16
8-74 I am service [0] Send at power-up 1 set-up FALSE - Uint8
8-75 Intialisation password [admin] 1 set-up FALSE 0 VisStr[21]
8-8* FC Port Diagnostics
8-80 Bus message count 0 N/A 1 set-up FALSE 0 Uint32
8-81 Bus error count 0 N/A 1 set-up FALSE 0 Uint32
8-82 Slave messages received 0 N/A 1 set-up FALSE 0 Uint32
8-83 Slave error count 0 N/A 1 set-up FALSE 0 Uint32
8-84 Slave messages sent 0 N/A 1 set-up FALSE 0 Uint32
8-85 Slave timeout errors 0 N/A 1 set-up FALSE 0 Uint32
8-88 Reset FC port diagnostics [0] Do not reset 1 set-up FALSE - Uint8
8-9* Bus Feedback
8-94 Bus feedback 1 0 N/A All set-ups FALSE 0 Int16
8-95 Bus feedback 2 0 N/A All set-ups FALSE 0 Int16
Parameter Lists Programming Guide
MG18B502 Danfoss A/S © 04/2018 All rights reserved. 111
