Danfoss VLT HVAC Basic Drive FC 101 Programming Guide

16-92 Warning word 0 N/A 1 set-up FALSE 0 Uint32
16-93 Warning word 2 0 N/A 1 set-up FALSE 0 Uint32
16-94 External status word 0 N/A 1 set-up FALSE 0 Uint32
16-95 External status word 2 0 N/A 1 set-up FALSE 0 Uint32
5.1.14 18-** Info & Readouts
Par. No. # Parameter description Default value 2-set-up Change
during
operation
Conversion
index
Type
18-1* Fire Mode Log
18-10 Fire mode log:event 0 N/A 1 set-up FALSE 0 Uint8
18-5* Ref. & Feedb.
18-50 Sensorless Readout [unit] 0 SensorlessUnit 1 set-up FALSE -3 Int32
5.1.15 20-** Drive Closed Loop
Par. No. # Parameter description Default value 2-set-up Change
during
operation
Conversion
index
Type
20-0* Feedback
20-00 Feedback 1 source [0] No function All set-ups FALSE – Uint8
20-01 Feedback 1 conversion [0] Linear All set-ups FALSE – Uint8
20-03 Feedback 2 source [0] No function All set-ups FALSE – Uint8
20-04 Feedback 2 conversion [0] Linear All set-ups FALSE – Uint8
20-2* Feedback/Setpoint
20-20 Feedback function [3] Minimum All set-ups FALSE – Uint8
20-8* PI Basic Settings
20-81 PI normal/inverse control [0] Normal All set-ups FALSE – Uint8
20-83 PI start speed [Hz] 0 Hz All set-ups FALSE -1 Uint16
20-84 On reference bandwidth 5% All set-ups FALSE 0 Uint8
20-9* PI Controller
20-91 PI anti windup [1] On All set-ups FALSE –- Uint8
20-93 PI proportional gain 0.50 N/A All set-ups FALSE -2 Uint16
20-94 PI integral time 20 s All set-ups FALSE -2 Uint32
20-97 PI feed forward factor 0% All set-ups FALSE 0 Uint16
Parameter Lists Programming Guide
MG18B502 Danfoss A/S © 04/2018 All rights reserved. 115
5 5
