3.12.7 16-9* Diagnosis Read-Outs
16-90 Alarm Word
Range: Function:
0* [0 - 0xFFFFFFFFUL ] View the alarm word sent via the serial
communication port in hex code.
16-91 Alarm Word 2
Range: Function:
0* [0 - 0xFFFFFFFFUL ] View the alarm word 2 sent via the
serial communication port in hex code.
16-92 Warning Word
Range: Function:
0* [0 - 0xFFFFFFFFUL ] View the warning word sent via the
serial communication port in hex code.
16-93 Warning Word 2
Range: Function:
0* [0 - 0xFFFFFFFFUL ] View the warning word 2 sent via the
serial communication port in hex code.
16-94 Ext. Status Word
Range: Function:
0* [0 - 0xFFFFFFFFUL ] Shows the extended status word sent
via the serial communication port in
hex code.
16-95 Ext. Status Word 2
Range: Function:
0* [0 - 0xFFFFFFFFUL ] Shows the extended status word 2 sent
via the serial communication port in
hex code.
16-97 Alarm Word 3
Range: Function:
0* [0 - 4294967295] View the alarm word 3 sent via the serial
communication port in hex code.
16-98 Warning Word 3
Range: Function:
0* [0 - 4294967295] View the warning word 3 sent via the
serial communication port in hex code.
3.13 Main Menu - Data Readouts 2 - Group
18
Parameters in this group are array parameters, where up to
10 fault logs can be viewed. [0] is the most recent logged
data, and [9] is the oldest. Fault codes, values, and time
stamp can be viewed for all logged data.
3.13.1 18-1* Fire Mode Log
18-10 FireMode Log:Event
Range: Function:
0* [0 - 255 ] View re mode event.
3.13.2 18-5* Ref. & Feedb.
18-50 Sensorless Readout [unit]
Range: Function:
0 Sensor-
lessUnit*
[-999999.999 -
999999.999
SensorlessUnit]
View the pressure or ow
resulting from the sensorless
calculations. This value is not the
value used for control. The value
is only updated if sensorless data
supports both ow and pressure.
Parameters
VLT
®
HVAC Basic Drive FC 101
84 Danfoss A/S © 04/2018 All rights reserved. MG18B502
