5.1.4 2-** Brakes
Par.
No. #
Parameter description Default value 2-set-up Change
during
operation
Conversion
index
Type
2-0* DC-Brake
2-00 DC Hold/Motor Preheat Current 50% All set-ups FALSE 0 Uint16
2-01 DC Brake Current 50% All set-ups FALSE 0 Uint16
2-02 DC Braking Time 10 s All set-ups FALSE -1 Uint16
2-04 DC Brake Cut In Speed 0 Hz All set-ups FALSE -1 Uint16
2-06 Parking Current 100% All set-ups FALSE 0 Uint16
2-07 Parking Time 3 s All set-ups FALSE -1 Uint16
2-1* Brake Energy Funct.
2-10 Brake Function [0] O All set-ups FALSE – Uint8
2-16 AC Brake, Max current 100% All set-ups FALSE -1 Uint16
2-17 Over-voltage Control [2] Enabled All set-ups FALSE – Uint8
5.1.5 3-** Reference/Ramps
Par.
No. #
Parameter description Default value 2-set-up Change
during
operation
Conversion
index
Type
3-0* Reference Limits
3-02 Minimum Reference 0 ReferenceFeedbackUnit All set-ups FALSE -3 Int32
3-03 Maximum Reference ExpressionLimit All set-ups FALSE -3 Int32
3-1* References
3-10 Preset Reference 0% All set-ups TRUE -2 Int16
3-11 Jog Speed [Hz] 5 Hz All set-ups TRUE -1 Uint16
3-14 Preset Relative Reference 0% All set-ups TRUE -2 Int16
3-15 Reference 1 Source [1] Analog Input 53 All set-ups FALSE – Uint8
3-16 Reference 2 Source [2] Analog Input 54 All set-ups FALSE – Uint8
3-17 Reference 3 Source [11] Local bus reference All set-ups FALSE – Uint8
3-4* Ramp 1
3-41 Ramp 1 Ramp Up Time ExpressionLimit All set-ups FALSE -2 Uint32
3-42 Ramp 1 Ramp Down Time ExpressionLimit All set-ups FALSE -2 Uint32
3-5* Ramp 2
3-51 Ramp 2 Ramp Up Time ExpressionLimit All set-ups FALSE -2 Uint32
3-52 Ramp 2 Ramp Down Time ExpressionLimit All set-ups FALSE -2 Uint32
3-8* Other Ramps
3-80 Jog Ramp Time ExpressionLimit All set-ups FALSE -2 Uint32
3-81 Quick Stop Ramp Time ExpressionLimit 1 set-up FALSE -2 Uint32
Parameter Lists
VLT
®
HVAC Basic Drive FC 101
108 Danfoss A/S © 04/2018 All rights reserved. MG18B502
