A-4 SD460 Laminating System

Bolt-Down Option

Thelaminatorincludesbolt‐downopeningsthatyoucanusetosecurethesystem

toamountingsurface.

Youneedthefollowingsupplies:

• Thebolt‐downkit(partno.509169‐001)containstwoM6wellnuts.

• TwoM6(6mm)screws,purchasedseparately.

Thelengthofthescrewsyouneeddependsonthethicknessofthemounting

surface.Thescrewlengthisthesurfacethickness+0.75inch(20mm).

• TwoM6washers,purchasedseparately.

• 1/4‐inch(7mm)drillbit.

1. Drilltwoholesinthemountingsurfacefollowingthedimensionsand

requirementsshowninthefollowingfigure :



Thisprocedureisoptional.
