22 PowerScan
®
RF Scanner
Table 2. Scanner YELLOW LED Functions
Table 3. Scanner BEEPER Functions
LED
INDICATION
DURATION COMMENT
Laser on indica-
tion
On Steady
The yellow LED illuminates
whenever the laser is on.
SPEAKER
INDICATION
DURATION COMMENT
Scanner Not
Currently
Linked
Six beeps consisting of 20 ms
on, 20 ms off
Indicates a bar code was
read before the scanner
was linked to a Base Sta-
tion.
Good Read
Beep
100 ms on (short)
250 ms on (medium)
500 ms on (long)
Three programmable func-
tions are available. This
indicates a bar code has
been read and decoded.
Partial Read
Bip
20 ms on
A very short beep ("bip") is
sounded when one bar
code of a two-bar code pair
has been successfully
decoded.
Base Station
Acknowledge-
ment Beep
100 ms on (short)
250 ms on (medium)
500 ms on (long)
Indicates a successful bar
code transmission to the
host (configurable), a suc-
cessful change of channel,
or a successful transmis-
sion of a new configuration
to the host.
