Label Formatting Command Functions
Class Series Programmer’s Manual 125
^ Set Count By Amount
This command allows applications using the increment / decrement field command to print more than
one label with the same field value before the field data is updated. All printers default to 1.
 Note: This command can only be issued once per label format. In addition, when alternate Control Codes
are enabled, the ^ character must be replaced by the @ character (hexadecimal 0x40). See
Control Codes.
Syntax:
^nn
Where:
^
- May be 0x55 or 0x40; see Control Codes.
nn
- Is a two-digit value that specifies the number of labels to be
generated before incrementing (or decrementing) the field value.
Sample:
<STX>L<CR>
13220000000000012345<CR>
-01<CR>
^02<CR>
Q0006<CR>
E<CR>
The sample prints two labels containing the same field value before decrementing the field. Six labels
are printed.
Special Label Formatting Command Functions
Two Special Label Formatting Commands, the <STX>S and the <STX>T, are entered directly into the
data field of label format records. Do not confuse them with System-Level Commands because the same
control character is used. If alternate control codes are enabled the <STX> becomes ‘~’ (hexadecimal
0x7E); see Control Codes.
Label Formatting Character Command Description
<STX>S
Recall global data and place in field
<STX>T
Print time and date
Table 6-2: Special Label Formatting Commands

Datamax A-4310 Specifications

General

Print Resolution	300 dpi
Print Speed	10 ips
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Print Technology	Thermal Transfer
Memory	16 MB DRAM / 8 MB Flash
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Tickets
Maximum Print Length	99 inches
Supported Barcode Types	Code 39, Code 128, UPC-A, UPC-E, EAN-8, EAN-13, Interleaved 2 of 5, Codabar, Postnet, PDF417
Operating Temperature	40°F to 104°F (4°C to 40°C)
Print Width	4.16" (105.7 mm)
Media Width	1.0" to 4.65" (25.4 mm to 118.1 mm)
Media Thickness	0.0025" to 0.010" (0.0635 mm to 0.254 mm)
