Appendix J – General Purpose Input Output Ports

230 Class Series Programmer’s Manual

Applicator Interface Card (Version 1)

The Applicator Interface Card (Version 1) is equipped with a GPIO Port, an Auxiliary (Serial B) Port and

two LEDs.

Auxiliary Port, J1

Green and Yellow LEDs

GPIO Port, J2

Applicator Interface Card

Connector

Pin-Outs

Applicator Interface Card Location and Connector Pin-outs (as found in some A-Class models)

Applicator Interface Card Jumper Locations
