Generating Label Formats
Class Series Programmer’s Manual 139
5. Images
An image record is used to print an image that is stored in a memory module. Images can be
printed only in Rotation 1 (see Input Image Data <STX>I).
Field Valid Inputs Meaning
a
1 Fixed Value
b
Y Image
c
1 to 9, A to Z, and a to z
Width Multiplier
d
1 to 9, A to Z, and a to z
Height Multiplier
eee
000 Fixed Value
ffff
0000 to 9999 Row
gggg
See Appendix K. Column
jj…j
ASCII string, up to 16 characters followed by a termination
character.
Image name
Table 8-11: Image Fields
6. Graphics
Using graphics, the printer can produce lines, boxes, polygons, and circles. This function is selected
by entering an X in field b. The values entered in the data field determine the sizes and shapes of
the objects to be drawn. Forms can be created using shaded boxes, complex logos, or even a simple
diagonal line without the need to download a graphics file to the printer. The following sub-
sections describe how to generate each kind of graphic.
Lines and Boxes
Lines and boxes are drawn by values that determine column and row starting position, length,
width, and wall thickness of the line or box (see Appendix K). Depending on the printer’s mode, all
measurements are interpreted as inches/100 or millimeters/10 (see <STX>m). The data field jj…j
is used to describe the line or box dimensions.
Segment Valid Inputs Meaning
a
1 Fixed value
b
X Line / Box
c
1 Fixed Value
d
1 Fixed Value
eee
000 Fixed Value
ffff
0000 to 9999 Row
gggg
0000-9999, see Appendix K. Column
jj…j
Lhhhvvv
lhhhhvvvv
Bhhhvvvbbbsss
bhhhhvvvvbbbbssss
Line*
Line**
Box***
Box****
Table 8-12: Line and Box Parameters
