Class Series Programmer’s Manual 177
Appendix F
Bar Code Summary Data
Bar code fonts have alpha names (left column, below). Uppercase alpha names will print bar codes with human-readable interpretations, if
supported. Lowercase alpha names will print bar codes only. Place the ID in field b of the Format Record header to cause the printer to encode the
data field using the associated bar code symbology, see Appendix G for details. See Table F-2 for default values. The column labeled “Linear
Scanner Supported” provides an indication that printers equipped with a Linear Scanner are capable of recognizing the associated symbology.
Bar
Code
ID
Symbology Length Checksum Valid ASCII Characters, decimal value representation
Linear
Scanner
Supported
A / a
Code 39 Varies No 32, 36, 37, 42, 43, 45-57, 65-90
B / b
UPC-A 11 Yes 48-57 Numeric only. Option V used in the 6th & 7th position
C / c
UPC-E 6 Yes 48-57 Numeric only
D / d
Interleaved 2 of 5 (I2 of 5) Varies No 48-57 Numeric only
E / e
Code 128 Varies M-103 32-127
F / f
EAN-13 12 Yes 48-57 Numeric only. Option V used in 7th & 8th position
G / g
EAN-8 7 Yes 48-57 Numeric only
H / h
HBIC Varies M-43 32, 36-39, 42, 43, 45-57, 65-90
I / i
Codabar Varies No 36, 43, 45-58, 65-68
J / j
Interleaved 2 of 5 w/ a modulo 10 checksum Varies M-10 48-57 Numeric only
K / k
Plessey Up to 14 M-10 48-57 Numeric only. Option + is last character for 2
nd
M-11
chksum
L / l
Interleaved 2 of 5 w/ modulo 10 checksum &
bearer bars
13 M-10 48-57 Numeric only
M / m
2 digit UPC addendum 2 Yes 48-57 Numeric only [1]
N / n
5 digit UPC addendum 5 Yes 48-57 Numeric only [1]
O / o
Code 93 Varies No 35-38, 42-58, 65-90, 97-122
p
Postnet Varies Yes 48-57 Numeric only
Q / q
UCC/EAN 128 19 Yes 48-57 Numeric only
R / r
UCC/EAN 128 K-Mart non-EDI 18 Yes 48-57 Numeric only
S / s
UCC/EAN 128 Random Weight 34 + Yes 48-57 Numeric only
T / t
Telepen Varies Yes Alphanumeric
U
UPS MaxiCode 84 Yes Alphanumeric
Table F-1: Bar Code Characteristics
