Dell 2330d - Laser Printer B/W Service Manual

Fuser removal
1. Remove the rear exit guide. See “Rear exit guide assembly with sensor and reversing solenoid
removal” on page 4-56.
2. Remove the two screws (A).
3. Partially pull the fuser forward for better access.
4. Push in on the cable connector cover (B), and remove.
4-20

Dell 2330d - Laser Printer B/W Specifications

General

Print Technology	Laser
Print Speed	Up to 35 ppm
Print Resolution	1200 x 1200 dpi
Standard Input Capacity	250 sheets
Processor Speed	400 MHz
Memory	64 MB
Operating System Compatibility	Windows, Mac, Linux
Connectivity	Ethernet
Maximum Paper Size	8.5 x 14 inch
Monthly Duty Cycle	50, 000 pages
