Dell 2330d - Laser Printer B/W Service Manual

Rear exit guide assembly with sensor and reversing solenoid removal
1. Remove the top cover. See “Top cover assembly removal” on page 4-61.
2. Remove the rear door and rear cover. See “Rear door and rear cover removal” on page 4-54.
3. Disconnect the narrow media sensor cable and the reversing solenoid cable (A).
4. Remove the six screws (B) from the rear exit guide assembly.
BBB
4-56

Dell 2330d - Laser Printer B/W Specifications

General

Print Technology	Laser
Print Speed	Up to 35 ppm
Print Resolution	1200 x 1200 dpi
Standard Input Capacity	250 sheets
Processor Speed	400 MHz
Memory	64 MB
Operating System Compatibility	Windows, Mac, Linux
Connectivity	Ethernet
Maximum Paper Size	8.5 x 14 inch
Monthly Duty Cycle	50, 000 pages
