Dell 2330d - Laser Printer B/W Service Manual

Fan removal
1. Remove the right side cover. See “Right side cover assembly removal” on page 4-58.
2. Disconnect the cable (A) from the controller board, and remove the two screws (B) holding the fan to the
right side frame.
3. Remove the fan.
A BB
4-16

Dell 2330d - Laser Printer B/W Specifications

General

Print Technology	Laser
Print Speed	Up to 35 ppm
Print Resolution	1200 x 1200 dpi
Standard Input Capacity	250 sheets
Processor Speed	400 MHz
Memory	64 MB
Operating System Compatibility	Windows, Mac, Linux
Connectivity	Ethernet
Maximum Paper Size	8.5 x 14 inch
Monthly Duty Cycle	50, 000 pages
