Dell 2330d - Laser Printer B/W Service Manual

Diagnostic aids 3-5
Diagnostics menu
Entering Diagnostics menu
1. Turn off the printer.
2. Press and hold and .
3. Turn on the printer.
4. Release the buttons when Performing Self Test displays.
Available tests
The menus display on the operator panel in the order shown:
Diagnostic menu settings
Note: Menus may vary depending on the features and options of the printer.
Registration See “Registration” on page 3-6.
Print tests See “Print tests” on page 3-7.
Hardware tests See “Hardware tests” on page 3-8.
Duplex tests (if installed) See “Duplex tests” on page 3-9.
Input tray tests See “Input tray tests” on page 3-10.
Output bin tests See “Output bin tests” on page 3-11.
Base sensor test See “Base sensor test (B. sensor test)” on page 3-11.
Printer setup See “Printer setup” on page 3-12.
EP setup See “EP setup” on page 3-13.
Event log See “Event log” on page 3-14.
Exit Diagnostics See “Exit Diagnostics” on page 3-15.

Dell 2330d - Laser Printer B/W Specifications

General

Print Technology	Laser
Print Speed	Up to 35 ppm
Print Resolution	1200 x 1200 dpi
Standard Input Capacity	250 sheets
Processor Speed	400 MHz
Memory	64 MB
Operating System Compatibility	Windows, Mac, Linux
Connectivity	Ethernet
Maximum Paper Size	8.5 x 14 inch
Monthly Duty Cycle	50, 000 pages
