Dell 2330d - Laser Printer B/W Service Manual

Right side cover assembly removal
Note: Leave the front cover closed when removing the right side cover assembly.
1. Remove the one screw (A) from behind the paper tray.
2. Remove the screw (B) from the bottom right side of the printer.
A
B
4-58

Dell 2330d - Laser Printer B/W Specifications

General

Print Technology	Laser
Print Speed	Up to 35 ppm
Print Resolution	1200 x 1200 dpi
Standard Input Capacity	250 sheets
Processor Speed	400 MHz
Memory	64 MB
Operating System Compatibility	Windows, Mac, Linux
Connectivity	Ethernet
Maximum Paper Size	8.5 x 14 inch
Monthly Duty Cycle	50, 000 pages
