Dell 2330d - Laser Printer B/W Service Manual

Diagnostic aids 3-9
Duplex tests
The following tests are used to determine if the duplex is working correctly:
• Quick Test
• Top Margin
• Left Margin
• Sensor Test
• Duplex Feed 1
Quick Test
The Quick Test contains the following information on a duplexed page:
• Print registration settings
• Alignment diamonds at the top and bottom
• Horizontal lines to check for skew
• General printer information, including current page count, installed memory, serial number,
and code level.
To print the duplexed Quick Test page:
1. Select Quick Test from the DUPLEX TESTS menu.
2. Select Single or Continuous by pressing or .
3. Press to print the page.
Top Margin
1.
Select Top Margin from the DUPLEX TESTS menu.
2. To change the margin value, press to increase the value or to decrease the value.
3. Press to save the desired margin value.
Left Margin
1.
Select Left Margin from the DUPLEX TESTS menu.
2. To change the margin value, press to increase the value or to decrease the value.
3. Press to save the desired margin value.
Sensor Test
This test is used to determine if the input sensor is operating correctly.
• If the sensor is operating correctly, then OP (Open) will appear on the display:
• Press to return to the DUPLEX TESTS menu.
Sensor Test
Input=OP

Dell 2330d - Laser Printer B/W Specifications

General

Print Technology	Laser
Print Speed	Up to 35 ppm
Print Resolution	1200 x 1200 dpi
Standard Input Capacity	250 sheets
Processor Speed	400 MHz
Memory	64 MB
Operating System Compatibility	Windows, Mac, Linux
Connectivity	Ethernet
Maximum Paper Size	8.5 x 14 inch
Monthly Duty Cycle	50, 000 pages
