Dell 2330d - Laser Printer B/W Service Manual

Rear door and rear cover removal
1. Open the rear door.
2. Pull the rear door up at an angle, disconnect the door from the notch (A), and remove.
3. Remove the two screws (B) from the top of the rear cover.
A
B
4-54

Dell 2330d - Laser Printer B/W Specifications

General

Print Technology	Laser
Print Speed	Up to 35 ppm
Print Resolution	1200 x 1200 dpi
Standard Input Capacity	250 sheets
Processor Speed	400 MHz
Memory	64 MB
Operating System Compatibility	Windows, Mac, Linux
Connectivity	Ethernet
Maximum Paper Size	8.5 x 14 inch
Monthly Duty Cycle	50, 000 pages
