Duplex Feed 1
1.
Select Duplex Feed 1 from the DUPLEX TESTS menu. The following will appear on the display:
2. A blank page will feed through the printer. The following will appear on the display:
3. Remove the blank page from the printer, and press to return to the DUPLEX TESTS menu.
Input tray tests
The INPUT TRAY TESTS setting is used to test the printer’s installed input trays and their sensors.
Feed Tests
The Feed Test observes the paper path of media as it passes through the printer. This setting contains the
following tests:
• Tray 1
• Tray 2
• MP Feeder, if installed
To observe the paper path, open the upper rear door during the feed test.
Note: The upper front door cannot be opened during the feed test.
The feed test can be performed by using media from any if the installed input sources. All pages used during this
test drop into the default output bin. For each installed input source, press to select Single or press and
to select Continuous. The Single test feeds one sheet of media to the default output bin. The Continuous
test feeds media to the default output bin until is pressed. The operator panel displays [Select Input
Tray] Feeding... while either of these tests perform.
Sensor Test
The Sensor Test verifies that the Tray 1, Tray 2, and MP Feeder (if installed) sensors are working correctly.
Press to select this test from the INPUT TRAY TESTS menu. [Select Input Tray...] Tray Present will
display on the operator panel.
Duplex Feed 1
Feeding...
Duplex Feed 1
Clear Paper...
3-10
